Introduction

An embankment refers to a volume of earthen material that is placed and compacted for the purpose of raising the grade of a roadway (or railway) above the level of the existing surrounding ground surface. A fill refers to a volume of earthen material that is placed and compacted for the purpose of filling in a hole or depression. Embankments or fills are constructed of materials that usually consist of soil, but may also include aggregate, rock, or crushed paving material.

Normally, the coarser fill materials are placed at or near the bottom or base of the embankment in order to provide a firm foundation for the embankment and also to facilitate drainage and prevent saturation. The top portion of an embankment usually is constructed of relatively high-quality, well-compacted subgrade material that is capable of supporting the overlying pavement layers and imposed wheel loadings without deflection or undesirable movement. The fill material used throughout the remainder of the embankment must be capable of meeting applicable specification quality requirements and be capable of being placed and compacted at or close to its maximum achievable density. The material is spread in relatively thin layers of 150 mm (6 in) to 200 mm (8 in) and each layer is compacted by rolling over it with heavy compaction equipment.

Materials

Many different types of soils may be suitable for use in the construction of an embankment or fill, ranging from granular soils (sand and gravel), which are highly desirable, to the more finely sized soils (silt and clay), which are usually somewhat less desirable. Certain types of soils (such as saturated clays and highly organic soils) are considered unsuitable for use as materials in embankment or fill construction. Regardless of the type(s) of soil(s) used to construct embankments or fills, the material should be well graded, capable of being well compacted, be within a proper range of moisture to optimize compaction, and be free of unsuitable or deleterious materials, such as tree roots, branches, stumps, sludge, metal, or trash.

Some oversize materials (over 100 mm (4 in) in size), such as rocks, large stones, reclaimed paving materials, or air-cooled slags, can be used for the construction of embankment bases. Although the use of oversize materials can result in a stable embankment base, the oversize materials should have strong particles that do not readily break down under the action of construction machinery, but which have a range of sizes so that void spaces are at least partially filled.
